Somfy Eolis 3D WireFree RTS Wind Sensor White (1816081)
Somfy Eolis 3D WireFree RTS Wind Sensor White (1816081)
Eolis 3D WireFree RTS wind sensor -- battery-powered wind protection for awnings
The Eolis 3D WireFree RTS is a wireless, battery-powered 3D motion sensor that detects horizontal, vertical, and lateral vibration from wind and automatically retracts a motorized awning once your set threshold is exceeded -- even while you're away.
Benefits
- Completely wireless, battery operated -- fits existing or new awning installs
- Patented technology detects wind movement in 3 directions (horizontal, vertical, lateral)
- Automatically protects the awning even when no one is home
- Built-in low-battery indicator
- Compatible with all RTS-powered systems, controls, and accessories
Specifications
| Protection Index | IP 44 |
| Dimensions | 6.02" L x 1.5" W x 0.98" H |
| Radio Frequency | 433.420 MHz |
| Range (open field) | 164 ft |
| Battery | 2x LR3 (AAA), 1.5V |
| Color | White |
| Operating temperature | -4°F to 140°F |
| Warranty | 5 years |
Compatible with: RTS-powered awning motors
Official Somfy documentation
- Eolis 3D Brochure (PDF)
- Eolis 3D RTS Manual (PDF)
- Eolis 3D Specification Sheet (PDF)
- Eolis 3D Quick Programming Guide (PDF)
- Eolis 3D Consumer Instructions (PDF)
Sold by ShadeMotorsDirect -- an authorized source for genuine Somfy motorized window shade, blind, and drapery parts.
Common questions
What does the Eolis 3D WireFree RTS wind sensor do?
It watches for movement caused by wind and tells your Somfy RTS motor to retract. Part 1816081 protects awnings, exterior solar screens and pergolas, and it keeps working when no one is home.
How does it detect wind?
The sensor reads motion in three directions: horizontal, vertical and lateral. When the movement passes the threshold you set, it sends the retract command over RTS radio.
How is it powered?
It runs on 2 LR3 (AAA) batteries, so the sensor needs no wiring at the awning. A built-in indicator warns you when the batteries run low.
What is the radio range?
Somfy rates the range at 164 ft in open field on 433.420 MHz. Walls and structures shorten that distance, so mount the sensor with a clear path to the motor or receiver. The housing carries an IP 44 rating.
Which motors and receivers does it work with?
It pairs with Somfy RTS motors and receivers. To add wind protection to a Somfy standard wired motor, the Universal RTS Receiver (1810627) provides RTS control and accepts Eolis sensors.
Does it come in other colors?
Yes. Somfy makes the Eolis 3D WireFree RTS in White (1816081), Black (1816082) and Off-White (1816083), so you can match the awning frame. All three share the same function.
Couldn't load pickup availability
How this motor compares
Verified Somfy specs for this motor and its closest alternatives.
| Specification | You're viewing
Somfy Eolis 3D WireFree RTS Wind Sensor White (1816081)
|
Somfy Eolis 3D WireFree RTS Wind Sensor Black (1816082)
|
Somfy Eolis 3D WireFree RTS Wind Sensor Off-White (1816083)
|
Somfy Eolis RTS 60 MPH Wind Sensor 24V DC Kit (1870709)
|
|---|---|---|---|---|
| Price | ||||
| Control | RTS radio | RTS radio | RTS radio | RTS radio |
| Power | Battery (2x AAA) | Battery (2x AAA) | Battery (2x AAA) | 24V DC wired |
| What's different | The product on this page | Close alternative | Close alternative | Close alternative |
| Buy | Currently viewing | View details | View details | View details |
Most recent reviews
Real help. Real parts. Fast delivery.
“Spoke with Colin. He configured my whole Somfy setup, and the products arrived in 3 days.”
“Great experience. Fast shipping and the exact part I needed.”
“Couldn’t find these Somfy parts anywhere else. Delivered on time, brand new.”
“I ordered the wrong remote at first, but customer support helped me find the correct replacement fast.”
“The part was exactly what I needed and worked right out of the box.”
“Fast shipping, fair pricing, and authentic Somfy product.”
“I had no idea which charger my motor needed. They helped me confirm it before I ordered.”
“Smooth process from start to finish. Product arrived quickly and fixed my issue.”
“Way easier than trying to search random websites for the right Somfy accessory.”
Guides for this product
Somfy Maestria RTS 550R2 Zip Screen Motor Sizing Guide
