Somfy USB to RS485 Adapter (9015260) for SDN Commissioning

Short answer: The Somfy USB to RS485 Adaptor for SDN (9015260) links a Windows laptop to the Somfy Digital Network bus. USB goes into the laptop, and a standard Cat5 or Cat6 cable runs from its RJ45 port to the SDN bus. With Somfy's Set pro software open, you configure RS485 motors, keypads and devices from one screen.

An SDN job lives or dies at commissioning. Every motor on the bus carries an address, and somebody has to name it, group it and set its limits before the keypads and the control system can do anything useful. The Somfy USB to RS485 Adaptor for SDN (9015260) is the piece of hardware that puts your laptop on that bus. Installers who search "usb to rs485" for a Somfy project usually want to know two things: will a generic converter do, and what else the laptop needs to talk to the motors.

The USB to RS485 adapter's job on an SDN install

Somfy describes 9015260 as a compact, USB-powered adapter that connects a Windows laptop running Set pro to the SDN bus. From there you configure motors, keypads and devices, and run setup, updates and diagnostics from one place. Somfy lists it under wired technology for interior blinds, draperies and shades, which matches where SDN gets specified: commercial facades, conference rooms and large residential projects with dozens of addressed shades.

The adapter has no radio and carries no control logic of its own. It translates. Your laptop speaks USB, the bus speaks RS485, and 9015260 sits between them so Set pro can read and write each device. Pull the cable at the end of the day and the system keeps running on its keypads, hubs and integration drivers.

Somfy's install documents for this part are the SDN Set pro By Somfy User Guide [V2.0], the Design Guide for SDN Connect [V1.0] and the SDN Motor Configuration Software 5.1 package. Keep all three on the laptop before you drive to site.

Verified specs for the Somfy USB to RS485 Adaptor (9015260)

Every figure below comes from Somfy's own product pages for ref 9015260 on somfypro.com and somfysystems.com.

Two of those rows shape the job. The 5 V USB supply means the adapter draws its power from the laptop, so you carry no extra brick or wall plug. The IP 20 rating and the 41 F floor mean it belongs indoors, in a conditioned space, during commissioning. Plan a cold-shell site visit around that.

RS485 motors, keypads and hubs it connects to

The adapter talks to any device that sits on the SDN bus. On the motor side that means the RS485 versions across the Sonesse range. The Somfy Sonesse 30 RS485 24V DC motor (1241144) is the common pick for lighter roller shades, at 2 Nm and 25 rpm on a 24V DC supply. Larger shades step up to Sonesse 40 and Sonesse 50 RS485 models with more torque on the same bus.

RS485 motors carry no radio receiver. A Telis or Situo remote will never pair with one, and a DecoFlex WireFree switch has nothing to talk to. Control on an SDN system comes through wired DecoFlex digital keypads, a hub, or a third-party control system driver. The adapter is how you set all of that up.

On the network side, the Somfy Data Hub V2 (1870951) gives you five RJ45 ports to branch the bus, which makes it a tidy place to land the laptop cable. Keypads and hubs need bus power, and the Somfy Bus and Sensor Station Power Supply (1822440) puts 24V DC on the SDN bus for up to 80 bus line devices, motors excluded. Motors draw their own power from the panel or enclosure that feeds them.

Generic USB to RS485 converters versus the Somfy adapter

A hardware store converter with a USB plug and two screw terminals looks similar on paper. The fitment question comes down to the bus connector and the software. Somfy's adapter terminates in an RJ45 port that takes a standard Cat5 or Cat6 patch cable, the same cable the SDN bus uses. Somfy lists it with Set pro and its own configuration software. A generic converter leaves you building an adapter cable by hand and guessing at the pinout, with no Somfy support path if a motor refuses to answer.

Integrators who also run a control system sometimes ask whether the laptop adapter replaces the gateway. It does not. The adapter is a service tool for configuration. Day-to-day control through a lighting or AV system runs through Somfy's interface products, such as the UAI Plus, covered in our UAI Plus SDN commissioning guide.

Laptop commissioning or the handheld RS485 Setting Tool

Somfy offers two ways to reach an RS485 motor. The USB adapter with Set pro covers the whole network from a laptop: motors, keypads and devices, plus setup, updates and diagnostics. The Somfy RS485 Setting Tool (9017142) is the handheld option for work at a single motor when opening a laptop on a ladder makes no sense.

Most SDN installers end up owning both. Budget them into the first SDN project. Both tools are reusable on the next job and the one after that, so the cost spreads across every building you commission.

Setup notes an installer asks about

Somfy publishes the commissioning procedure in the SDN Set pro By Somfy User Guide [V2.0]. Follow that document for the screen-by-screen steps, since menus change between software versions. A few planning points hold across versions:

• Bring a Windows laptop. Somfy names Windows for Set pro.
• Carry a spare Cat5 or Cat6 patch cable long enough to reach a Data Hub port or bus junction from a comfortable working spot.
• Confirm bus power is live before you plug in, since keypads and hubs on the bus run from the 1822440 or another Somfy bus supply.
• Label each motor with its address as you commission it. The motor label and the Set pro project file should match when you hand the job over.

For RS485 motor wiring details, the Sonesse 30 RS485 tube fit and SDN wiring guide and the bus power supply guide cover the bus side in more depth. Install guides for each motor sit in our Somfy spec sheet library, and the rest of the SDN line is in our Somfy SDN digital network collection.

Sources: Somfy Pro product page and somfysystems.com product page for ref 9015260 (USB to RS485 Adaptor for SDN); Somfy documents listed there, SDN Set pro By Somfy User Guide [V2.0] and Design Guide SDN Connect [V1.0].

FAQ

Does the Somfy USB to RS485 adapter need its own power supply?

No. Somfy lists 9015260 as USB-powered at 5 V, so it runs from the laptop's USB port. Keypads and hubs on the SDN bus still need bus power from a Somfy supply such as the 1822440, and RS485 motors draw power from their own panel or enclosure. The adapter adds nothing to the bus power budget you plan for those devices.

Which software works with the USB to RS485 adaptor?

Somfy pairs 9015260 with Set pro by Somfy on a Windows laptop, and its product page also lists the SDN Motor Configuration Software 5.1 package. Download the SDN Set pro By Somfy User Guide [V2.0] from the same page before your site visit. It holds the commissioning steps for motors, keypads and devices, along with the update and diagnostic tools.

Can I use a generic USB to RS485 converter on Somfy SDN?

Somfy builds and supports 9015260 for SDN, with an RJ45 port that accepts a standard Cat5 or Cat6 cable and a match to Set pro. A generic converter usually ends in screw terminals, which leaves you making a cable and guessing the pinout. For a commissioning tool you will reuse on every SDN job, the Somfy adapter keeps the support path clean.

Will the adapter let me pair an RTS remote with an RS485 motor?

No. RS485 motors such as the Sonesse 30 RS485 (1241144) carry no radio receiver, so no RTS remote can pair with them. The adapter configures devices on the wired SDN bus, including motors and DecoFlex digital keypads. Wireless or app control on an SDN system comes through a hub or a control system driver set up with the same laptop tools.
