RS485 Motor Limit Setting & Address Reader Tool -- handheld commissioning for RS485/SDN motors
This handheld Somfy tool sets travel limits and reads addresses on Somfy RS485 motors without a laptop, making on-site commissioning and service of SDN/RS485 shading installations faster and simpler.
Benefits
- Sets upper and lower travel limits on Somfy RS485 motors
- Reads motor addresses for network commissioning and record-keeping
- Handheld -- no laptop required at the window
- Speeds up installation and service calls on RS485/SDN projects
Specifications
| Part type | RS485 limit setting and address reader tool |
| For system | Somfy Digital Network (SDN) / RS485 motors |
| Genuine part | Somfy |
Compatible with: Somfy RS485 / SDN motors including Sonesse RS485 models
Official Somfy documentation
- SDN Connect Brochure (PDF)
- SDN Connect – Design Guide (PDF)
- RS485 Setting Tool – Somfy Pro Product Page
Sold by ShadeMotorsDirect -- an authorized source for genuine Somfy motorized window shade, blind, and drapery parts.
Common questions
What does the RS485 Motor Limit Setting & Address Reader Tool (9017142) do?
It is a handheld tool that sets travel limits on Somfy RS485 motors and reads their network addresses. Somfy lists it as the tool required to set limits on RS485 motors.
Which motors does it work with?
Somfy lists RS485 motors such as the Sonesse 506S2 RS485 Motor (1002286), Sonesse 50 510S2 RS485 SDN 120V Motor (1002287), Sonesse 30 RS485 24V DC (1241144) and Sonesse Ultra 50 504A8 RS485 24V DC Motor (1134022).
How does it connect?
It connects to each motor by wire through the RS485 interface. That lets an installer set limits and read addresses at the window during commissioning or a service call.
Why read motor addresses?
Each RS485 motor on a Somfy Digital Network carries an address. Reading it at the motor lets you record which shade sits where, which helps when you program keypads or a control system.
What warranty does it carry?
Somfy covers the RS485 Motor Limit Setting & Address Reader Tool with a 5-year warranty. It is built for installers who commission and service Somfy RS485 and SDN shading projects.
Is there a tool for Sonesse 30 DCT and Glydea ULTRA motors?
Yes. The Sonesse 30 ST30 Limit Setting Tool (9014599) sets limits on Sonesse 30 dry contact motors, Glydea ULTRA motors and Irismo DCT motors, and it can stay in place as a wired control.
