Somfy Sonesse 30 WireFree Rollease 1.5" Crown & Drive (9020674)
Somfy Sonesse 30 WireFree Rollease 1.5" Crown & Drive (9020674)
Ships in 1-2 business days. US shipping $15 flat.
Returns: 30 days from delivery, unused and in original packaging, with an RMA. A 35% restocking fee applies and the customer pays return shipping, unless the item is defective or we made an error. Custom and engraved items can be returned only if defective. Full return policy
Not sure this fits? Ask our tech team
Your case has been assigned to Colin. He'll be in touch shortly via email.
RollEase 1.5" Crown & Drive -- connect a Somfy WireFree motor to 1.5" RollEase tube
This genuine Somfy crown and drive set adapts a compatible Somfy WireFree motor to a 1.5" RollEase roller tube. The crown supports the motor inside the tube while the drive wheel locks into the tube's internal profile, transferring torque smoothly without set screws through the tube.
Benefits
- Purpose-built fit for 1.5" RollEase tube profiles
- Drive engages the tube's internal ribs -- no screws through the tube, no wobble
- Keeps the shade aligned and quiet across its full travel
- Quick, tool-free motor-to-tube assembly for fabricators and retrofits
Specifications
| Tube | RollEase 1.5" |
| Type | Crown & drive set |
Compatible with: Somfy Roll Up 28 WireFree motors (1241150 / 1241162 / 1240291 / 1240292), Sonesse 28 WireFree (1003297), and Sonesse 30 WireFree (1003128) motors
Official Somfy documentation
Sold by ShadeMotorsDirect -- an authorized source for genuine Somfy motorized window shade, blind, and drapery parts.
Common questions
What does the RollEase 1.5 in Crown & Drive do?
Part 9020674 is a crown and drive set that fits a compatible Somfy motor into a 1.5 in RollEase roller tube. The drive locks into the tube's internal profile and turns the tube, while the crown supports the motor.
Which motors does it fit?
Somfy lists 18 compatible motors across the Sonesse 30, Sonesse 28, Sonesse ULTRA 30, Roll Up 28 and Roll Up 30 families. Examples in this store include the Sonesse 30 WireFree (1003128) and the Roll Up 28 WireFree RTS V2 (1241150).
Does it fit other RollEase tube sizes?
This set fits 1.5 in RollEase tube. For RollEase 2 in tubes, use the Sonesse 30 WireFree and Ultra Crown & Drive Kit (9021017). For RollEase 1.25 in tubes, use the RollEase 1.25 in Crown & Drive (9025815).
What else do I need to mount the motor?
Plan for hardware at the bracket end. Related parts in this store include the RollEase Sonesse 30 Motor Bracket Adapter Plate (9016378) and the RollEase SkyLine Bracket Set with 2 inch projection (9017910).
What is it made of, and how does it attach?
Somfy makes the set from plastic and backs it with a 5-year warranty. The drive engages the tube's internal ribs, so no screws pass through the tube.
Couldn't load pickup availability
Replace a worn crown or drive, or order the right set for a new roller.
Match the set to your motor head and your tube size.
123- 1Crown Grips the inside of the tube.
- 2Drive Turns the tube.
- 3Motor fitting Connects to the motor.
Replacing one
-
1
Take the shade down
Cut power and lift the roller out of its brackets.
-
2
Pull the motor
Slide the motor out of the tube.
-
3
Swap the part
Pull off the worn crown or drive and fit the Sonesse 30 WireFree Rollease 1.5" Crown & Drive.
-
4
Slide it back
Insert the motor drive end first and rehang the shade.
Not sure of your tube? Send us a photo of the tube end and your motor label. We'll confirm before you order. Ask us
Starting new
-
1
Check your tube
Measure across the outside of the tube end and note the shape: round, octagonal or a brand profile.
-
2
Fit the crown
Slide the crown onto the motor until it seats against the head.
-
3
Fit the drive
Push the drive onto the output shaft until it locks.
-
4
Slide the motor in
Insert the motor into the tube, drive end first.
Planning a new install? Send us the window size and a photo. We'll build the parts list with you. Ask us
Motors the Sonesse 30 WireFree Rollease 1.5" Crown & Drive works with
Somfy lists these motors as compatible with part 9020674.
More Somfy motors work with it too. Ask us if yours isn't listed.
Somfy backs the Sonesse 30 WireFree Rollease 1.5" Crown & Drive for 5 years. We handle the claim.
Somfy warranty on the Sonesse 30 WireFree Rollease 1.5" Crown & Drive, part 9020674.
- What Somfy covers
- Defects in materials and workmanship, for 5 years from purchase.
- If it fails
- Email us your order number. We arrange the replacement with Somfy.
- Where it comes from
- ShadeMotorsDirect is an authorized Somfy distributor. You get the US version, new in Somfy packaging.
- Returns
- Unopened items in original packaging. Ask us for an RA number before you ship.
- Questions
- Call or chat, 8:00 AM - 7:30 PM ET.
- Somfy documents
- WireFree Databook (PDF)
