Somfy T5/T6 70mm Octagonal Aluminum Drive (9011878)
Somfy T5/T6 70mm Octagonal Aluminum Drive (9011878)
Ships in 1-2 business days. US shipping $15 flat.
Returns: 30 days from delivery, unused and in original packaging, with an RMA. A 35% restocking fee applies and the customer pays return shipping, unless the item is defective or we made an error. Custom and engraved items can be returned only if defective. Full return policy
Not sure this fits? Ask our tech team
Your case has been assigned to Colin. He'll be in touch shortly via email.
Somfy T5/T6 70mm Octagonal Aluminum Drive -- aluminum drive wheel for 70mm octagonal tube
Somfy part 9011878 is an aluminum drive wheel for Simu T5 and T6 operators, including the DMI5 and DMI6 ranges, on 70mm octagonal tube. It mounts on the operator and transfers its torque to the roller.
Benefits
- Genuine Somfy part 9011878
- Aluminum drive wheel for 70mm octagonal tube
- Fits Simu T5 and T6 operators, including DMI5 and DMI6
Specifications
| Part type | Drive wheel, aluminum |
| Tube | 70mm octagonal |
| Fits | Simu T5 and T6 operators (DMI5, DMI6) |
| Genuine part | Somfy 9011878 |
Compatible with: Simu T5 and T6 operators, including DMI5 and DMI6 motors, per Somfy's compatibility list for this part
Official Somfy documentation
Sold by ShadeMotorsDirect -- an authorized source for genuine Somfy motorized window shade, blind, and drapery parts.
Common questions
What is this part?
It is a 70mm octagonal aluminum drive wheel for Somfy and Simu tubular motors. Somfy's internal designation reads DRIVE LT50/60 70 OCTAG AL, and the wheel turns a 70mm octagonal roller tube.
Which motors does it fit?
Somfy lists 46 compatible motors in the DMI5, DMI5Hz, DMI6, DMI6Hz, T5, T5Hz, T5 ZsP Hz, T6 and T6Hz ranges, rated from 10Nm to 100Nm. Examples here include the DMI5 50Nm 12rpm 120V (2000776) and DMI6Hz 100Nm 14rpm 120V (2007156).
What tube does it fit?
It fits a 70mm octagonal roller tube. Somfy lists rolling shutters as the application, which matches the larger exterior tubes the DMI and T-series motors drive.
What else do I need for the install?
Pair it with a 70mm octagonal crown that fits your motor head, plus a bracket made for your motor. For Simu T6 motors, we carry the Simu T6 Operator Bracket 100mm x 100mm Square (9530018).
What warranty applies to this drive?
Somfy covers 9011878 with its 5-year warranty. It is made of aluminum and listed for motors rated up to 100Nm, so it serves heavy rolling shutter installs.
Couldn't load pickup availability
Replace a worn crown or drive, or order the right set for a new roller.
Match the set to your motor head and your tube size.
12- 1Octagon profile Matches your 70mm octagonal tube.
- 2Center socket Slides onto the motor.
Replacing one
-
1
Take the shade down
Cut power and lift the roller out of its brackets.
-
2
Pull the motor
Slide the motor out of the tube.
-
3
Swap the part
Pull off the worn crown or drive and fit the T5/T6 70mm Octagonal Aluminum Drive.
-
4
Slide it back
Insert the motor drive end first and rehang the shade.
Not sure of your tube? Send us a photo of the tube end and your motor label. We'll confirm before you order. Ask us
Starting new
-
1
Check your tube
Measure across the outside of the tube end and note the shape: round, octagonal or a brand profile.
-
2
Fit the crown
Slide the crown onto the motor until it seats against the head.
-
3
Fit the drive
Push the drive onto the output shaft until it locks.
-
4
Slide the motor in
Insert the motor into the tube, drive end first.
Planning a new install? Send us the window size and a photo. We'll build the parts list with you. Ask us
Motors the T5/T6 70mm Octagonal Aluminum Drive works with
Somfy lists these motors as compatible with part 9011878.
More Somfy motors work with it too. Ask us if yours isn't listed.
Somfy backs the T5/T6 70mm Octagonal Aluminum Drive for 5 years. We handle the claim.
Somfy warranty on the T5/T6 70mm Octagonal Aluminum Drive, part 9011878.
- What Somfy covers
- Defects in materials and workmanship, for 5 years from purchase.
- If it fails
- Email us your order number. We arrange the replacement with Somfy.
- Where it comes from
- ShadeMotorsDirect is an authorized Somfy distributor. You get the US version, new in Somfy packaging.
- Returns
- Unopened items in original packaging. Ask us for an RA number before you ship.
- Questions
- Call or chat, 8:00 AM - 7:30 PM ET.
