Somfy Roller Shade Motor Kit and the Parts Each Shade Needs

Short answer: A Somfy roller shade motor kit comes down to four parts: the motor, a crown and drive matched to the tube, a bracket or adaptor plate for the shade hardware, and a control. Choose the motor by power source and tube inside diameter first. The Roll Up 28 WireFree RTS V2 fits tubes from 1.05 in, and the Sonesse 30 family needs 1.13 in.

Roller shades are the most common job for a Somfy tubular motor. The motor slides inside the roller tube, turns it, and stops at the limits set during programming. A motor ordered on its own leaves two or three parts missing on install day. This guide lists the parts a Somfy roller shade motor needs, with the Somfy references we stock and the store prices on October 13, 2026.

The four parts in a Somfy roller shade motor kit

A motorized roller shade runs on four Somfy parts plus the shade itself. Each one has a separate job, and each one has to agree with the tube or the bracket it meets.

Power adds a fifth item on some motors. A WireFree motor needs a charger, and a 24V DC motor needs a power supply. The idle end of the tube comes from the shade system, outside the motor kit.

Choose the motor: battery, 24V DC or 120V AC

Start at the window. A window with no outlet nearby points to a WireFree motor with the lithium-ion battery built in. Low voltage wiring in a remodel opens up the 24V DC Sonesse 30. Large, heavy shades on line voltage move up to the Sonesse 50.

The Roll Up 28 WireFree RTS V2 is the entry point. Somfy rates it for mid-to-large interior shades, and it stores 12 RTS transmitters with a 656.2 ft open-field range. The Sonesse ULTRA 30 WireFree RTS doubles the torque to 2 Nm and drops the noise to 42 dB, the quietest motor in this table. The Sonesse 30 RTS 24V DC matches that torque at a faster 25 rpm and runs from a power supply with no charging trips.

Torque follows fabric weight, width and drop. Blackout fabric on a wide window needs more than a sheer screen of the same size. Our guide to sizing a Somfy shade motor works through that math. The Sonesse 50 sits on the LT50 platform and takes LT50 crowns, drives and brackets, a separate parts family from the 28 and 30 mm motors below.

Crown and drive sets for the roller tube

The crown and drive set is the part most often missed. Somfy sizes each set to a tube maker, profile and diameter, so two tubes of the same nominal size can need different sets. Measure the inside of the tube and note the maker before ordering.

For RollEase tubes, Somfy publishes two sets that share one motor list. The Somfy RollEase 1.5" Crown & Drive (9020674) fits the RollEase 1.5 in tube and sells for $7.00. The Somfy Crown & Drive for RollEase/ZMC 2" Profiled Tube (9021017) fits RollEase and ZMC 2 in profiled tube at $11.95. Somfy lists the same 18 motors for both sets, among them the Roll Up 28 WireFree RTS V2, the Sonesse ULTRA 30 WireFree RTS and the Sonesse 30 RTS 24V DC.

That shared list helps on mixed jobs. One motor reference can run a 1.5 in tube in a bedroom and a 2 in tube in the living room with a change of set.

Other tube brands take other sets. Use 28 and 30 mm crowns and drives on these motors, since 40 mm parts will not seat. Our Somfy crowns, drives and brackets guide sorts the profiles by motor platform.

Brackets and adaptor plates for the shade hardware

The motor head mounts to the bracket at one end of the shade. Somfy builds adaptor plates so its motors fit the bracket systems shade fabricators already use. The Somfy Motor Adaptor Plate for RollEase SkyLine & ZMC XL Series Brackets (9016378) mates 26 Somfy motors to those two bracket families. The list includes the Roll Up 28 WireFree RTS V2, the Sonesse ULTRA 30 WireFree RTS and the Sonesse 30 RTS 24V DC, and the plate sells for $4.84 in white.

Check two things before ordering a plate: the motor reference it names and the bracket family on the shade. Shades on other bracket systems need the plate Somfy names for that system. Our guide to fitting a Somfy motor to an existing shade covers plates for other brands and the tube checks that come first.

Charger, power supply and remote

Somfy names the Somfy Lithium-ion Charger, V2 Head (9025166) as the charger for the Roll Up 28 WireFree RTS V2 and the Sonesse ULTRA 30 WireFree RTS. It sells for $33.95. Somfy also lists an 8 in extension charging cable for cassette shades and a WireFree Li-ion solar panel kit for the Roll Up 28 V2, which suit shades mounted out of reach.

The Sonesse 30 RTS 24V DC needs low voltage power. For one motor, Somfy lists the Somfy 24V DC 1.67 A Wall Mount Power Supply (1822209) at $52.87. Groups of 5, 10, 15 or 20 motors run from Somfy power distribution enclosure kits.

Each motor in this guide carries a built-in RTS receiver, so any Somfy RTS control drives it with no control wire. The Somfy Situo 1 RTS Pure remote (1870571) runs one shade or one group for $77.95. A Situo 5 adds separate channels for separate windows, and a TaHoma Switch adds app and voice control. Pairing the first remote follows the motor's own Somfy instructions, which sit in our Somfy spec library.

Example kits at today's prices

The three kits below assume a RollEase tube and RollEase SkyLine or ZMC XL brackets. Prices are store prices on October 13, 2026, before tax and shipping.

A second shade in the same room shares the charger and the remote. One 9025166 charger serves both battery motors in this guide, and one Situo 1 can drive a group. Browse the full motor range in our Somfy Sonesse roller shade motors collection.

Somfy roller shade motor kit FAQ

Do I need a separate crown and drive for a Somfy roller shade motor?

Plan on one. Somfy sizes crown and drive sets to the tube maker, profile and inside diameter, and the set on the motor has to match your tube. For RollEase tubes, Somfy lists the 1.5 in set 9020674 and the 2 in profiled set 9021017 for the Roll Up 28 WireFree RTS V2, the Sonesse ULTRA 30 WireFree RTS and the Sonesse 30 RTS 24V DC.

What tube size does a Somfy roller shade motor need?

Somfy publishes a minimum tube inside diameter for each motor. The Roll Up 28 WireFree RTS V2 needs 1.05 in. The Sonesse ULTRA 30 WireFree RTS and the Sonesse 30 RTS 24V DC need 1.13 in, and the Sonesse 50 506S2 RTS RH needs 1.85 in. Measure the inside of the tube, since wall thickness eats into the outside figure.

Can I add a Somfy motor to a roller shade I already own?

Often, yes. The tube inside diameter has to clear the motor, Somfy has to publish a crown and drive for the tube profile, and the motor head needs a plate or bracket that fits the shade hardware. RollEase and ZMC shades are a common match. Check the torque against the fabric weight before ordering.

Which Somfy roller shade motor is the quietest?

Among the motors in this guide, the Sonesse ULTRA 30 WireFree RTS (1003310) carries the lowest published figure at 42 dB. The Sonesse 50 506S2 RTS RH follows at 45.1 dB, the Sonesse 30 RTS 24V DC at 47 dB and the Roll Up 28 WireFree RTS V2 at 54 dB. Bedrooms and media rooms suit the ULTRA line.

Sources: Somfy Pro e-catalog pages for 1241150, 1003310, 1241142, 1001806, 9020674, 9021017 and 9016378.
